FUTURA SMOVE - CANADA Partial extension - A6155-1

FUTURA SMOVE - CANADA

Partial extension - A6155

Partial extension runner fixed to the drawer by clip

  • Runner length from 250 to 600 mm (10"-24")
  • Dynamic load capacity 34 kg (75 lbs)
  • Partial extension
Fluid, silent and progressive sliding movement

It is available in three versions: with traditional Self-closing, with Push opening in handle-less furniture and with Smove decelerated closing.

FUTURA SMOVE - CANADA Partial extension - A6155-2
Futura is suitable for all drawer opening applications, both with partial and full-extension.
  • Load capacity: 75 LBS (34 Kg) dynamic/100 LBS (45 Kg) static - ANSI GRADE 1.
  • Smove decelerated closing.
  • Drawer height adjustment +2.5 mm with clip A710.610.
  • Finish: bright zinc-plated.
A6155/25

Part-extension runner fixed to the drawer by clip.

Runner length: 10" (250 mm)

Min. depth of the cabinet: 250 mm

A6155/30

Part-extension runner fixed to the drawer by clip.

Runner length: 12" (300 mm)

Min. depth of the cabinet: 300 mm

A6155/35

Part-extension runner fixed to the drawer by clip.

Runner length: 14" (350 mm)

Min. depth of the cabinet: 350 mm

A6155/40

Part-extension runner fixed to the drawer by clip.

Runner length: 16" (400 mm)

Min. depth of the cabinet: 400 mm

A6155/45

Part-extension runner fixed to the drawer by clip.

Runner length: 18" (450 mm)

Min. depth of the cabinet: 450 mm

A6155/50

Part-extension runner fixed to the drawer by clip.

Runner length: 20" (500 mm)

Min. depth of the cabinet: 500 mm

A6155/55

Part-extension runner fixed to the drawer by clip.

Runner length: 22" (550 mm)

Min. depth of the cabinet: 550 mm

A6155/60

Part-extension runner fixed to the drawer by clip.

Runner length: 24" (600 mm)

Min. depth of the cabinet: 600 mm

A710.610
Height adjustable clip
A199800755009
Template for drawer drilling and 1-way adjustable clip fixing
A825104145

Spacer

Thickness 4.5 mm

To be used to compensate for different assembly widths or the projection of the door

A825104160

Spacer

Thickness 6 mm

To be used to compensate for different assembly widths or the projection of the door

A6869400000202

Stabilizer for drawers

To be fitted on both right and left sides of the drawer.
Cam adjustment to allow a perfect bearing of the rollers on the cabinet side.
It improves the overall stability of the drawer.

V234X164I

Wood screw

ø 4 x 16 mm
Pre-drilling ø 2 x 2 mm

V136X114I

Euroscrews

Drilling ø 5 x 10 mm

V136X154I

Euroscrews

Drilling ø 5 x 14 mm

Pozi screwdriver D2A7XCXCP

Pozi screwdriver
