FUTURA SELF CLOSING - CANADA Full-extension - A655-1

FUTURA SELF CLOSING - CANADA

Full-extension - A655

Full-extension runner fixed to the drawer by clip

  • Runner length from 250 to 600 mm (10"-24")
  • Dynamic load capacity 34 kg (75 Lbs)
  • Full-extension
Fluid, silent and progressive sliding movement

It is available in three versions: with traditional Self-closing, with Push opening in handle-less furniture and with Smove decelerated closing.

FUTURA SELF CLOSING - CANADA Full-extension - A655-2
Futura is suitable for all drawer opening applications, both with partial and full-extension.
  • Load capacity: 75 LBS (34 Kg) dynamic/100 LBS (45 Kg) static - ANSI GRADE 1.
  • Self-closing device on drawer.
  • Drawer height adjustment +2.5 mm with clip A710.610.
  • Drawer height adjustment +2.5, side adjustment ±1.5 mm, depth adjustment ±2 mm with clip A750.010.
  • Finish: bright zinc-plated.
A655/25 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 10" (250 mm)

Min. depth of the cabinet: 260 mm

A655/27 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 11" (270 mm)

Min. depth of the cabinet: 280 mm

A655/30 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 12" (300 mm)

Min. depth of the cabinet: 310 mm

A655/35 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 14" (350 mm)

Min. depth of the cabinet: 360 mm

A655/40 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 16" (400 mm)

Min. depth of the cabinet: 410 mm

A655/45 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 18" (450 mm)

Min. depth of the cabinet: 460 mm

A655/50 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 20" (500 mm)

Min. depth of the cabinet: 510 mm

A655/55 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 22" (550 mm)

Min. depth of the cabinet: 555 mm

A655/60 CP6

Full-extension runner fixed to the drawer by clip.

Runner length: 24" (600 mm)

Min. depth of the cabinet: 605 mm

A710.610
Height adjustable clip
A750.010
6-way adjustable clip
A199800755009
Template for drawer drilling and 1-way adjustable clip fixing
A199800755010
Template for drawer drilling and 6-way adjustable clip fixing
A825104145

Spacer

Thickness 4.5 mm

To be used to compensate for different assembly widths or the projection of the door

A825104160

Spacer

Thickness 6 mm

To be used to compensate for different assembly widths or the projection of the door

A6869400000202

Stabilizer for drawers

To be fitted on both right and left sides of the drawer.
Cam adjustment to allow a perfect bearing of the rollers on the cabinet side.
It improves the overall stability of the drawer.

V234X164I

Wood screw

ø 4 x 16 mm
Pre-drilling ø 2 x 2 mm

V136X114I

Euroscrews

Drilling ø 5 x 10 mm

V136X154I

Euroscrews

Drilling ø 5 x 14 mm

Pozi screwdriver D2A7XCXCP

Pozi screwdriver
